ResidentialNew Install
9-Circuit Subpanel for Workshop
Detached woodworking shop in Hillsborough — 100A subpanel with nine circuits including 240V for the table saw and dust collector.
Customer was running an extension cord from the house to power his table saw. He wanted to do it right.
We pulled a 100A feeder from the main panel, trenched 50 ft of buried conduit to the detached shop, installed a Square D QO subpanel with nine circuits, and dedicated 240V circuits for the table saw, dust collector, and air compressor. Two GFCI 20A receptacle circuits cover hand tools.
Specs
- Feed
- 100A from main panel
- Circuits
- 9 (3× 240V, 6× 120V)
- Trench length
- 50 ft buried PVC
Before & after
Before
After
